(10PCS) NDS8858H FSC Trans MOSFET N/P-CH 30V 6.3A/4.8A 8-Pin SOIC

  • $5.00
    Unit price per
Tax included.

Only 145 left!

THIS LISTING IS FOR (10PCS) OF NDS8858H BY FAIRCHILD SEMICONDUCTOR

SPECIFICATIONS

Mfr Package Description SOIC-8
REACH Compliant Yes
EU RoHS Compliant Yes
Status Discontinued
Configuration COMMON DRAIN, 2 ELEMENTS WITH BUILT-IN DIODE
Drain Current-Max (Abs) (ID) 6.3 A
Drain Current-Max (ID) 6.3 A
Drain-source On Resistance-Max 0.035 ohm
DS Breakdown Voltage-Min 30.0 V
FET Technology METAL-OXIDE SEMICONDUCTOR
JESD-30 Code R-PDSO-G8
JESD-609 Code e3
Moisture Sensitivity Level 1
Number of Elements 2.0
Number of Terminals 8
Operating Mode ENHANCEMENT MODE
Operating Temperature-Max 150.0 Cel
Package Body Material PLASTIC/EPOXY
Package Shape RECTANGULAR
Package Style SMALL OUTLINE
Peak Reflow Temperature (Cel) 260
Polarity/Channel Type N-CHANNEL AND P-CHANNEL
Power Dissipation-Max (Abs) 2.5 W
Qualification Status Not Qualified
Sub Category FET General Purpose Power
Surface Mount YES
Terminal Finish MATTE TIN
Terminal Form GULL WING
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Transistor Application SWITCHING
Transistor Element Material SILICON
