(10PC) TISP4395H3LMR-S Thyristor Surge Protection Device 320V 600 mA DO-92 ROHS
(10PC) TISP4395H3LMR-S Thyristor Surge Protection Device 320V 600 mA DO-92 ROHS
(10PC) TISP4395H3LMR-S Thyristor Surge Protection Device 320V 600 mA DO-92 ROHS

(10PC) TISP4395H3LMR-S Thyristor Surge Protection Device 320V 600 mA DO-92 ROHS

Tax included.
Only 200 left!
THIS IS FOR (10PC) OF TISP4395H3LMR-S BY BOURNS
Thyristor Surge Protection Device 320V 600 mA DO-92 ROHS

Manufacturer Bourns
Product Category Thyristor Surge Protection Devices - TSPD
Breakover Voltage VBO 395 V
Breakover Current IBO Max 600 mA
Non Repetitive On-State Current 55 A, 60 A
Rated Repetitive Off-State Voltage VDRM 320 V
Off-State Leakage Current @ VDRM IDRM 5 uA
Holding Current Ih Max 600 mA
On-State Voltage 3 V
Off-State Capacitance CO 22 pF to 92 pF
Minimum Operating Temperature - 40 C
Maximum Operating Temperature + 85 C
Mounting Style Through Hole
Package / Case DO-92-2
Packaging Reel
Current Rating 5 A
Product Type TSPDs
Series TISP4xxxH3LM
Subcategory Thyristors
Tradename TISP
