(10PC) SFV4R-1STBE1LF 4 Position FFC, FPC Connector Contacts, Bottom 0.020" R/A
Tax included.
THIS IS FOR (10PCS) OF SFV4R-1STBE1LF BY AMPHENOL/FCI
4 Position FFC, FPC Connector Contacts, Bottom 0.020" R/A
Mfr Amphenol ICC (FCI)
Series SFV-R
Package Tape & Reel (TR)
Active
Flat Flex Type FFC, FPC
Mounting Type Surface Mount, Right Angle
Connector/Contact Type Contacts, Bottom
Number of Positions 4
Pitch 0.020" (0.50mm)
Termination Solder
FFC, FCB Thickness 0.30mm, 0.33mm
Height Above Board 0.071" (1.80mm)
Locking Feature Slide Lock
Cable End Type Straight, Tapered
Contact Material Phosphor Bronze
Contact Finish Gold
Housing Material Polyamide (PA), Nylon, Glass Filled
Actuator Material Polyphenylene Sulfide (PPS), Glass Filled
Zero Insertion Force (ZIF)
Voltage Rating 50V
Operating Temperature -55°C ~ 105°C
Material Flammability Rating UL94 V-0
Current Rating (Amps) 0.5A
Contact Finish Thickness -
Housing Color Black
Actuator Color Black
Mating Cycles 20
Base Product Number SFV4R
