(10PC) SFV4R-1STBE1LF 4 Position FFC, FPC Connector Contacts, Bottom 0.020" R/A
(10PC) SFV4R-1STBE1LF 4 Position FFC, FPC Connector Contacts, Bottom 0.020" R/A
(10PC) SFV4R-1STBE1LF 4 Position FFC, FPC Connector Contacts, Bottom 0.020" R/A
(10PC) SFV4R-1STBE1LF 4 Position FFC, FPC Connector Contacts, Bottom 0.020" R/A
(10PC) SFV4R-1STBE1LF 4 Position FFC, FPC Connector Contacts, Bottom 0.020" R/A
(10PC) SFV4R-1STBE1LF 4 Position FFC, FPC Connector Contacts, Bottom 0.020" R/A
(10PC) SFV4R-1STBE1LF 4 Position FFC, FPC Connector Contacts, Bottom 0.020" R/A

(10PC) SFV4R-1STBE1LF 4 Position FFC, FPC Connector Contacts, Bottom 0.020" R/A

Tax included.
Only 100 left!
THIS IS FOR (10PCS) OF SFV4R-1STBE1LF BY AMPHENOL/FCI
4 Position FFC, FPC Connector Contacts, Bottom 0.020" R/A

Mfr  Amphenol ICC (FCI)
Series  SFV-R
Package  Tape & Reel (TR)
Active
Flat Flex Type  FFC, FPC
Mounting Type  Surface Mount, Right Angle
Connector/Contact Type  Contacts, Bottom
Number of Positions  4
Pitch  0.020" (0.50mm)
Termination  Solder
FFC, FCB Thickness  0.30mm, 0.33mm
Height Above Board  0.071" (1.80mm)
Locking Feature  Slide Lock
Cable End Type  Straight, Tapered
Contact Material  Phosphor Bronze
Contact Finish  Gold
Housing Material  Polyamide (PA), Nylon, Glass Filled
Actuator Material  Polyphenylene Sulfide (PPS), Glass Filled
Zero Insertion Force (ZIF)
Voltage Rating  50V
Operating Temperature  -55°C ~ 105°C
Material Flammability Rating  UL94 V-0
Current Rating (Amps)  0.5A
Contact Finish Thickness  -
Housing Color  Black
Actuator Color  Black
Mating Cycles  20
Base Product Number  SFV4R
