(10PC) H11G3SD Optoisolator Darlington with Base Output 5300Vrms 1 Channel 6-SMD
Tax included.
THIS IS FOR (10 PCS) OF H11G3SD BY FSC
Optoisolator Darlington with Base Output 5300Vrms 1 Channel 6-SMD
Manufacturer: (FSC) onsemi
Product Category: Transistor Output Optocouplers
RoHS: NO
Package / Case: SMD-DIP-6
Output Type: Photodarlington
Number of Channels: 1 Channel
If - Forward Current: 60 mA
Maximum Collector Emitter Voltage: 55 V
Isolation Voltage: 5300 Vrms
Maximum Collector Emitter Saturation Voltage: 1.2 V
Vf - Forward Voltage: 1.5 V
Vr - Reverse Voltage: 6 V
Pd - Power Dissipation: 260 mW
Minimum Operating Temperature: - 55 C
Maximum Operating Temperature: + 100 C
Packaging: Reel
Packaging: Cut Tape
Brand: onsemi / Fairchild
Configuration: 1 Channel
Height: 4.45 mm
Length: 8.89 mm
Product Type: Transistor Output Optocouplers
1000
Subcategory: Optocouplers
Width: 6.86 mm
Unit Weight: 0.014110 oz
