(100 PCS) ZTX1048A ZETEX TRANS NPN 17.5V 4A E-LINE TO-92 ROHS
Tax included.
THIS IS FOR (100 PCS) OF ZTX1048A BY ZETEX
TRANS NPN 17.5V 4A E-LINE TO-92 ROHS
Manufacturer: ZETEX / Diodes Incorporated
Product Category: Bipolar Transistors - BJT
RoHS: YES
REACH - SVHC:
Technology: Si
Mounting Style: Through Hole
Package / Case: TO-92-3
Transistor Polarity: NPN
Configuration: Single
Maximum DC Collector Current: 4 A
Collector- Emitter Voltage VCEO Max: 17.5 V
Collector- Base Voltage VCBO: 50 V
Emitter- Base Voltage VEBO: 5 V
Collector-Emitter Saturation Voltage: 245 mV
Pd - Power Dissipation: 1 W
Gain Bandwidth Product fT: 150 MHz
Minimum Operating Temperature: - 55 C
Maximum Operating Temperature: + 200 C
Series: ZTX1048
Packaging: Bulk
Brand: ZETEX / Diodes Incorporated
Continuous Collector Current: 4 A
DC Collector/Base Gain hfe Min: 280 at 10 mA, 2 V, 300 at 500 mA, 2 V, 300 at 1 A, 2 V, 220 at 4 A, 2 V, 50 at 20 A, 2 V
DC Current Gain hFE Max: 280 at 10 mA, 2 V
Product Type: BJTs - Bipolar Transistors
4000
