(100 PCS) MLK1005S15NJT000 TDK FIXED IND 15NH 300MA 500 MOHM ROHS 0402 (1005)
Tax included.
THIS LISTING IS FOR (100 PCS) OF MLK1005S15NJT000 BY TDK
FIXED IND 15NH 300MA 500 MOHM ROHS 0402 (1005 Metric)
Manufacturer TDK Corporation
Series MLK
Packaging Cut Tape (CT)
Part Status Not For New Designs
Type Multilayer
Material - Core Non-Magnetic
Inductance 15nH
Tolerance ±5%
Current Rating (Amps) 300mA
Current - Saturation -
Shielding Unshielded
DC Resistance (DCR) 500mOhm Max
Q @ Freq 7 @ 100MHz
Frequency - Self Resonant 4GHz
Ratings -
Operating Temperature -55°C ~ 125°C
Inductance Frequency - Test 100MHz
Mounting Type Surface Mount
Package / Case 0402 (1005 Metric)
Supplier Device Package 0402 (1005 Metric)
Size / Dimension 0.039" L x 0.020" W (1.00mm x 0.50mm)
Height - Seated (Max) 0.024" (0.60mm)
