(100 PCS) FZT705TA ZETEX TRANS PNP DARL 120V 2A SOT-223 ROHS
Tax included.
THIS LISTING IS FOR (100 PCS) OF FZT705TA BY ZETEX
TRANS PNP DARL 120V 2A SOT-223 ROHS
Manufacturer: (ZETEX) Diodes Incorporated
Product Category: Darlington Transistors
RoHS: YES
Configuration: Single Dual Collector
Transistor Polarity: PNP
Collector- Emitter Voltage VCEO Max: 120 V
Emitter- Base Voltage VEBO: 10 V
Collector- Base Voltage VCBO: 140 V
Maximum DC Collector Current: 2 A
Maximum Collector Cut-off Current: 0.1 uA
Pd - Power Dissipation: 2 W
Mounting Style: SMD/SMT
Package / Case: SOT-223
Minimum Operating Temperature: - 55 C
Maximum Operating Temperature: + 150 C
Series: FZT705
Packaging: Cut Tape
Packaging: Reel
DC Current Gain hFE Max: 3000
Height: 1.65 mm
Length: 6.7 mm
Width: 3.7 mm
Brand: Diodes Incorporated
Continuous Collector Current: - 2 A
DC Collector/Base Gain hfe Min: 3000 at 10 mA at 5 V, 3000 at 100 mA at 5 V, 3000 at 1 A at 5 V, 2000 at 2 A at 5 V
Product Type: Darlington Transistors
Factory Pack Quantity: 1000
Subcategory: Transistors
Unit Weight: 0.006702 oz
