(10 PCS) TIC253M-S BOURNS TRIAC Standard 600V 20A Through Hole SOT-93 ROHS
Tax included.
THIS LISTING IS FOR (10 PCS) OF TIC253M-S BY BOURNS
TRIAC Standard 600V 20A Through Hole SOT-93 ROHS
Manufacturer Bourns Inc.
Series -
Packaging Tube
Part Status Obsolete
Triac Type Standard
Voltage - Off State 600V
Current - On State (It (RMS)) (Max) 20A
Voltage - Gate Trigger (Vgt) (Max) 2V
Current - Non Rep. Surge 50, 60Hz (Itsm) 150A @ 50Hz
Current - Gate Trigger (Igt) (Max) 50mA
Current - Hold (Ih) (Max) 40mA
Configuration Single
Operating Temperature -40°C ~ 110°C (TC)
Mounting Type Through Hole
Package / Case TO-218-3
Supplier Device Package SOT-93
Base Part Number TIC253
