(10 PCS) TIC201D-S BOURNS TRIAC Standard 400 V 2.5 A Through Hole TO-220 ROHS
(10 PCS) TIC201D-S BOURNS TRIAC Standard 400 V 2.5 A Through Hole TO-220 ROHS
(10 PCS) TIC201D-S BOURNS TRIAC Standard 400 V 2.5 A Through Hole TO-220 ROHS

(10 PCS) TIC201D-S BOURNS TRIAC Standard 400 V 2.5 A Through Hole TO-220 ROHS

Tax included.
Only 100 left!
THIS IS FOR (10 PCS) OF TIC201D-S BY BOURNS
TRIAC Standard 400 V 2.5 A Through Hole TO-220 ROHS

Category
Discrete Semiconductor Products
Thyristors
TRIACs

Manufacturer Bourns Inc.
Series -
Packaging Tube
Part Status Obsolete
Triac Type Standard
Voltage - Off State 400 V
Current - On State (It (RMS)) (Max) 2.5 A
Voltage - Gate Trigger (Vgt) (Max) 2.5 V
Current - Non Rep. Surge 50, 60Hz (Itsm) 12A @ 50Hz
Current - Gate Trigger (Igt) (Max) 25 mA
Current - Hold (Ih) (Max) 30 mA
Configuration Single
Operating Temperature -40°C ~ 110°C (TC)
Mounting Type Through Hole
Package / Case TO-220-3
Supplier Device Package TO-220
Base Product Number TIC201
