(10 PCS) SFH615A-2 INFINEON Optocoupler DC-IN 1-CH Transistor DC-OUT 4-Pin PDIP
Tax included.
THIS LISTING IS FOR (10 PCS) OF SFH615A-2 BY INFINEON
Optocoupler DC-IN 1-CH Transistor DC-OUT 4-Pin PDIP
Manufacturer:
Optocoupler DC-IN 1-CH Transistor DC-OUT 4-Pin PDIP
Manufacturer:
| Vishay/Infineon | ||
| Product Category: | Transistor Output Optocouplers | |
| Package / Case: | PDIP-4 | |
| Output Type: | NPN Phototransistor | |
| Number of Channels: | 1 Channel | |
| If - Forward Current: | 60 mA | |
| Maximum Collector Emitter Voltage: | 70 V | |
| Maximum Collector Current: | 100 mA | |
| Isolation Voltage: | 5300 Vrms | |
| Maximum Collector Emitter Saturation Voltage: | 0.4 V | |
| Vf - Forward Voltage: | 1.65 V | |
| Vr - Reverse Voltage: | 6 V | |
| Pd - Power Dissipation: | 150 mW | |
| Maximum Operating Temperature: | + 100 C | |
| Minimum Operating Temperature: | - 55 C | |
| Packaging: | Tube | |
| Brand: | Vishay/Infineon | |
| Configuration: | 1 Channel |
|
| Current Transfer Ratio: | 125 % |
|
| Fall Time: | 2 us |
|
| Height: | 3.81 mm |
|
| Length: | 4.83 mm |
|
| Rise Time: | 2 us |
