(10 PCS) RJSL-002TC1 TAIMAG 10/100 BASE-TX Filtered SMD RJ45 Ethernet Connector
Tax included.
THIS IS FOR (10 PCS) OF RJSL-002TC1 BY TAIMAG
10/100 BASE-TX Filtered SMD RJ45 Ethernet Connector
10/100 BASE-TX Filtered SMD Connector Module
MODEL NO : RJSL-002TC1
Features:
◎ RoHS Compliant
◎ Fully shielded magnetics protect data from internally generated digital noise
◎ Reduces the overall length of the signal path for improved common mode
performance
◎ Implements full common mode termination scheme with used and unused
twisted pairs
◎ Meets IEEE802.3 Baseline Wander Compensation specification
◎ Integrates high voltage capacitor to chassis ground
◎ Supports all major transceivers with matched turns ration and complete
integration of specified termination
◎ Design for 100base-tx transmission over UTP-5 cable
◎ Operating TEMP. range: -40 to +85 ℃ ℃
◎ Storage TEMP. range: -55 to + 125 ℃ ℃
◎ Primary OCL inductance: 350µH MIN. at 100KHz/0.1Vrms with 8mA DC bias
2. Materials and Finish
A. Contact:
RJ Contact : Phosphor Bronze, Thickness=0.30mm
Finish : Contact Area :5µ”min. Gold over 50μ”min. Nickel
RJ Joint Contact : Brass, Thickness=0.20mm
Finish : 80µ”min. Sn over 50μ”min. Nickel
LED Joint Contact : Brass, Thickness=0.20mm
Finish : 80µ”min. Sn over 50μ”min. Nickel
B. Plastic Part :
(1) Set Housing : Thermoplastic, PA-9T, Black
UL FILE NO. : E59481
Manufacturer : Kuraray CO.,LTD.
Grade : 4830G
Flame Class : UL 94V-0
(2) Insert : Thermoplastic, PA-9T, Black
UL FILE NO. : E59481
Manufacturer : Kuraray CO.,LTD.
Grade : 4830G
Flame Class : UL 94V-0
(3) Spacer : Thermoplastic, PA-9T, Black
UL FILE NO. : E59481
Manufacturer : Kuraray CO.,LTD.
Grade : 4830G
Flame Class : UL 94V-0
