(10 PCS) MF-MSMF160-2 BOURNS PTC RESETTABLE 1.60A 8V 1812
Tax included.
THIS LISTING IS FOR (10 PCS) OF MF-MSMF160-2 BY BOURNS
PTC RESETTABLE 1.60A 8V 1812
(200 STOCK. WILL MAKE DEALS ON LARGER QUANTITIES. SEND OFFERS)
PTC RESETTABLE 1.60A 8V 1812
(200 STOCK. WILL MAKE DEALS ON LARGER QUANTITIES. SEND OFFERS)
MF-MSMF160-2 Part Details & Parametric
| EU RoHS |
Compliant
|
| Maximum Voltage Rating | 8V |
| Typical Power Dissipation (W) | 0.8 |
| Hold Current (A) | 1.6 |
| Trip Current (A) | 2.8 |
| Maximum Post Trip Resistance (Ohm) | 0.099 |
| Maximum Current Rating (A) | 100 |
| Application | Hard Disk Drives|PC Motherboards|PC Peripherals |
| Mounting | Surface Mount |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Minimum Initial Resistance (Ohm) | 0.035 |
| Number of Terminals | 2 |
| Maximum Trip Time (s) | 2@8A |
| Product Depth (mm) | 3.41(Max) |
| Product Height (mm) | 0.85(Max) |
| Agency Approvals | CSA/TUV/UL |
| Packaging | Tape and Reel |
| Product Length (mm) | 4.73(Max) |
| Package/Case | 1812 |
