(10 PCS) IRFS7440TRLPBF IR N-Channel 40 V 120A (Tc) 208W (Tc) SMD TO-263 (D²Pak)
Tax included.
THIS LISTING IS FOR (10 PCS) OF IRFS7440TRLPBF BY IR
N-Channel 40 V 120A (Tc) 208W (Tc) SMD TO-263 (D²Pak) ROHS
Manufacturer: Infineon (IR)
Product Category: MOSFET
RoHS: Y
Technology: Si
Mounting Style: SMD/SMT
Package / Case: TO-252-3
Transistor Polarity: N-Channel
Number of Channels: 1 Channel
Vds - Drain-Source Breakdown Voltage: 40 V
Id - Continuous Drain Current: 208 A
Rds On - Drain-Source Resistance: 2.5 mOhms
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Vgs th - Gate-Source Threshold Voltage: 3.9 V
Qg - Gate Charge: 135 nC
Minimum Operating Temperature: - 55 C
Maximum Operating Temperature: + 175 C
Pd - Power Dissipation: 208 W
Channel Mode: Enhancement
Tradename: StrongIRFET
Packaging: Cut Tape
Packaging: Reel
Configuration: Single
Height: 2.3 mm
Length: 6.5 mm
Transistor Type: 1 N-Channel
Width: 6.22 mm
Brand: Infineon / IR
Forward Transconductance - Min: 88 S
Fall Time: 68 ns
Product Type: MOSFET
Rise Time: 68 ns
Factory Pack Quantity: 800
Subcategory: MOSFETs
Typical Turn-Off Delay Time: 115 ns
Typical Turn-On Delay Time: 24 ns
Part # Aliases: IRFS7440TRLPBF SP001552344
Unit Weight: 0.011640 oz
