(10 PCS) FDMS3500 FSC Trans MOSFET N-CH 75V 9.2A 8-Pin Power 56 ROHS
Tax included.
THIS IS FOR (10 PCS) OF FDMS3500 BY FSC
Trans MOSFET N-CH 75V 9.2A 8-Pin Power 56 ROHS
Manufacturer: onsemi / Fairchild
Product Category: MOSFET
RoHS: YES
REACH - SVHC:
Technology: Si
Mounting Style: SMD/SMT
Package / Case: Power-56-8
Transistor Polarity: N-Channel
Number of Channels: 1 Channel
Vds - Drain-Source Breakdown Voltage: 75 V
Id - Continuous Drain Current: 9.2 A
Rds On - Drain-Source Resistance: 14.5 mOhms
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Vgs th - Gate-Source Threshold Voltage: 1 V
Qg - Gate Charge: 91 nC
Minimum Operating Temperature: - 55 C
Maximum Operating Temperature: + 150 C
Pd - Power Dissipation: 2.5 W
Channel Mode: Enhancement
Tradename: PowerTrench
Series: FDMS3500
Packaging: Reel
Packaging: Cut Tape
Brand: onsemi / Fairchild
Configuration: Single
Fall Time: 6 ns
Height: 1.1 mm
Length: 6 mm
Product Type: MOSFET
Rise Time: 9 ns
3000
Subcategory: MOSFETs
Transistor Type: 1 N-Channel
Typical Turn-Off Delay Time: 48 ns
Typical Turn-On Delay Time: 16 ns
Width: 5 mm
Unit Weight: 0.002402 oz
