(10 PCS) CDRH6D38NP-330NC Sumida Fixed Inductors 33uH 1.1A 30% SMD ROHS
Tax included.
THIS LISTING IS FOR (10 PCS) CDRH6D38NP-330NC BY Sumida
Fixed Inductors 33uH 1.1A 30% SMD ROHS
Manufacturer Sumida America Components Inc.
Series CDRH6D38
Packaging Tape & Reel (TR)
Part Status Active
Type -
Material - Core Ferrite
Inductance 33µH
Tolerance ±30%
Current Rating (Amps) 1.1A
Current - Saturation -
Shielding Shielded
DC Resistance (DCR) 124mOhm Max
Q @ Freq -
Frequency - Self Resonant -
Ratings -
Operating Temperature -40°C ~ 100°C
Inductance Frequency - Test 100kHz
Mounting Type Surface Mount
Package / Case Nonstandard
Supplier Device Package -
Size / Dimension 0.264" L x 0.264" W (6.70mm x 6.70mm)
Height - Seated (Max) 0.157" (4.00mm)
