(50 PCS) ATMXT224-CCU ATMEL Analog Circuit 1 Func 224 Channel CMOS PBGA49 ROHS
Tax included.
THIS IS FOR (50 PCS) OF ATMX224-CCU BY ATMEL
Analog Circuit 1 Func 224 Channel CMOS PBGA49 ROHS
Mfr Package Description UFBGA-49
EU RoHS Compliant Yes
Status Active
Analog IC - Other Type ANALOG CIRCUIT
JESD-30 Code S-PBGA-B49
Number of Channels 224
Number of Functions 1
Number of Terminals 49
Operating Temperature-Min -20.0 Cel
Operating Temperature-Max 85.0 Cel
Package Body Material PLASTIC/EPOXY
Package Code VFBGA
Package Equivalence Code BGA49,7X7,25
Package Shape SQUARE
Package Style GRID ARRAY, VERY THIN PROFILE, FINE PITCH
Seated Height-Max 0.6 mm
Supply Voltage-Nom (Vsup) 1.8 V
Supply Voltage-Min (Vsup) 1.71 V
Supply Voltage-Max (Vsup) 3.47 V
Surface Mount YES
Technology CMOS
Temperature Grade INDUSTRIAL
Terminal Form BALL
Terminal Pitch 0.65 mm
Terminal Position BOTTOM
Length 5.0 mm
Width 5.0 mm
