(10 PCS) ABS10M LITEON Bridge Rectifier Diode 1 Phase 1A 1000V Silicon SMD ROHS
Tax included.
THIS IS FOR (10 PCS) OF ABS10M BY LITEON
Bridge Rectifier Diode 1 Phase 1A 1000V Silicon SMD ROHS
Part #: ABS10M
Part Category: Diodes
Manufacturer: Lite-On Semiconductor Corp.
Description: Bridge Rectifier Diode, 1 Phase, 1A, 1000V V(RRM), Silicon
REACH Compliant Yes
Status Active
Diode Type BRIDGE RECTIFIER DIODE
Breakdown Voltage-Min 1000.0 V
Configuration BRIDGE, 4 ELEMENTS
Diode Element Material SILICON
JESD-30 Code R-PDSO-G4
Non-rep Pk Forward Current-Max 24.0 A
Number of Elements 4.0
Number of Phases 1.0
Number of Terminals 4
Operating Temperature-Min -55.0 Cel
Operating Temperature-Max 150.0 Cel
Output Current-Max 1.0 A
Package Body Material PLASTIC/EPOXY
Package Shape RECTANGULAR
Package Style SMALL OUTLINE
Rep Pk Reverse Voltage-Max 1000.0 V
Surface Mount YES
Terminal Form GULL WING
Terminal Position DUAL
Additional Feature UL RECOGNIZED
