(10 PCS) 74438323047 WURTH FIXED IND 4.7UH 940MA 388 MOHM 20% SMD 2520 ROHS
(10 PCS) 74438323047 WURTH FIXED IND 4.7UH 940MA 388 MOHM 20% SMD 2520 ROHS

(10 PCS) 74438323047 WURTH FIXED IND 4.7UH 940MA 388 MOHM 20% SMD 2520 ROHS

Tax included.
Only 50 left!
THIS LISTING IS FOR (10 PCS) OF 74438323047 BY WURTH
FIXED IND 4.7UH 940MA 388 MOHM 20% SMD 2520 ROHS

Manufacturer Würth Elektronik
Series WE-MAPI
Packaging REEL
Part Status Active
Type Molded
Material - Core Metal Composite
Inductance 4.7µH
Tolerance ±20%
Current Rating (Amps) 940mA
Current - Saturation 1.75A
Shielding Shielded
DC Resistance (DCR) 388mOhm Max
Q @ Freq -
Frequency - Self Resonant 35MHz
Ratings -
Operating Temperature -40°C ~ 125°C
Inductance Frequency - Test 100kHz
Mounting Type Surface Mount
Package / Case 1008 (2520 Metric)
Supplier Device Package 1008 (2520 Metric)
Size / Dimension 0.098" L x 0.079" W (2.50mm x 2.00mm)
Height - Seated (Max) 0.039" (1.00mm)
