(5 PCS) PALCE22V10H-25PC/4 Lattice EE Programmable Logic Device 25ns PDIP24 PIN
Tax included.
THIS LISTING IS FOR (1 PCS) OF PALCE22V10H-25PC/4 BY AMD/LATTICE
EE Programmable Logic Device 25ns PDIP24 PIN
Manufacturer: Advanced Micro Devices, Inc.
Description: EE PLD, 25ns, PDIP24
EE Programmable Logic Device 25ns PDIP24 PIN
Part #: PALCE22V10H-25PC/4
Part Category: Programmable Logic ICsManufacturer: Advanced Micro Devices, Inc.
Description: EE PLD, 25ns, PDIP24
| Mfr Package Description | 0.300 INCH, SKINNY, PLASTIC, DIP-24 |
| Status | Discontinued |
| Programmable Logic Type | EE PLD |
| Architecture | PAL-TYPE |
| Clock Frequency-Max | 33.3 MHz |
| JESD-30 Code | R-PDIP-T24 |
| JESD-609 Code | e0 |
| Number of Dedicated Inputs | 11 |
| Number of I/O Lines | 10 |
| Number of Inputs | 22 |
| Number of Outputs | 10 |
| Number of Product Terms | 132 |
| Number of Terminals | 24 |
| Operating Temperature-Min | 0.0 Cel |
| Operating Temperature-Max | 75 Cel |
| Organization | 11 DEDICATED INPUTS, 10 I/O |
| Output Function | MACROCELL |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | DIP |
| Package Equivalence Code | DIP24,.3 |
| Package Shape | RECTANGULAR |
| Package Style | IN-LINE |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED |
| Power Supplies | 5 |
| Propagation Delay | 25 ns |
| Qualification Status | Not Qualified |
| Seated Height-Max | 5.08 mm |
| Sub Category | Programmable Logic Devices |
| Supply Voltage-Nom | 5 V |
| Supply Voltage-Min | 4.5 V |
| Supply Voltage-Max | 5.5 V |
| Surface Mount | NO |
| Technology | CMOS |
| Temperature Grade | COMMERCIAL EXTENDED |
| Terminal Finish | Tin/Lead (Sn/Pb) |
| Terminal Form | THROUGH-HOLE |
| Terminal Pitch | 2.54 mm |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| Length | 30.73 mm |
| Width | 7.62 mm |
