(1 PCS) DS1E-S-DC24V AROMAT Electromechanical Relay SPDT 3A 24VDC
Tax included.
THIS LISTING IS FOR (1 PCS) OF DS1E-S-DC24V BY AROMAT
Electromechanical Relay SPDT 3A 24VDC
(248 STOCK. WE WILL MAKE DEALS ON LARGER QUANTITIES. SEND OFFERS)
Electromechanical Relay SPDT 3A 24VDC
(248 STOCK. WE WILL MAKE DEALS ON LARGER QUANTITIES. SEND OFFERS)
DS1E-S-DC24V Part Details & Parametric
| Maximum AC Voltage Rating (V) | 250 |
| Maximum DC Voltage Rating (V) | 220 |
| Relay Construction | Non-Latching |
| Product Height (mm) | 9.9 |
| Product Depth (mm) | 9.9 |
| Product Length (mm) | 15 |
| Seal | Sealed |
| Contact Form | 1 Form C |
| Coil Suppression Diode | No |
| LED Indicator | No |
| Push to Test Button | No |
| Maximum Switching Current (A) | 3 |
| Termination Style | PC Pin |
| DC Coil Voltage (V) | 24 |
| Coil Current (mA) | 8.3 |
| Coil Resistance (Ohm) | 2.88K |
| Maximum Switching Power | 60W|125VA |
| Mounting | Through Hole |
| Contact Arrangement | SPDT |
| Contact Material | Silver/Gold Clad |
| Minimum Dropout Voltage | 2.4VDC |
| Operate Time (ms) | 10 |
| Type | General Purpose Relay |
| Number of Terminals | 5 |
| Packaging | Tube|Case |
| Maximum Pick-Up Voltage | 19.2VDC |
| Maximum Operating Temperature (°C) | 70 |
| Minimum Operating Temperature (°C) | -40 |
