(1 PC) XC2C128-7CP132I XILINX IC CPLD 128MC 7NS 132BGA

Xilinx CoolRunner-II CPLDs deliver the high speed and ease of use associated with the XC9500/XL/XV CPLD family with the extremely low power versatility of the XPLA3 family in a single CPLD. This means that the exact same parts can be used for high-speed data communications/ computing systems and leading edge portable products, with the added benefit of In System Programming. Low power consumption and high-speed operation are combined into a single family that is easy to use and cost effective. Clocking techniques and other power saving features extend the users’ power budget. The design features are supported starting with Xilinx ISE® 4.1i WebPACK tool.

Key Features

Optimized for 1.8V systems

Industry’s fastest low power CPLD

Densities from 32 to 512 macrocells

Industry’s best 0.18 micron CMOS CPLD

Optimized architecture for effective logic synthesis

Multi-voltage I/O operation — 1.5V to 3.3V

Advanced system features

Fastest in system programming · 1.8V ISP using IEEE 1532 (JTAG) interface

On-The-Fly Reconfiguration (OTF)

IEEE1149.1 JTAG Boundary Scan Test

Optional Schmitt trigger input (per pin)

Multiple I/O banks on all devices

Unsurpassed low power management · DataGATE external signal control

Flexible clocking modes · Optional DualEDGE triggered registers · Clock divider (÷ 2,4,6,8,10,12,14,16) · CoolCLOCK

Global signal options with macrocell control · Multiple global clocks with phase selection per macrocell · Multiple global output enables · Global set/reset

Abundant product term clocks, output enables and set/resets

Efficient control term clocks, output enables and set/resets for each macrocell and shared across function blocks

Advanced design security

Open-drain output option for Wired-OR and LED drive

Optional bus-hold, 3-state or weak pullup on select I/O pins

Optional configurable grounds on unused I/Os

Mixed I/O voltages compatible with 1.5V, 1.8V, 2.5V, and 3.3V logic levels on all parts

SSTL2_1,SSTL3_1, and HSTL_1 on 128 macrocell and denser devices

Hot pluggable

PLA architecture

Superior pinout retention

100% product term routability across function block

Wide package availability including fine pitch:

Chip Scale Package (CSP) BGA, Fine Line BGA, TQFP, PQFP, VQFP, and QFN packages

Pb-free available for all packages

Design entry/verification using Xilinx and industry standard CAE tools

Free software support for all densities using Xilinx® WebPACK™ tool

Industry leading nonvolatile 0.18 micron CMOS process

Guaranteed 1,000 program/erase cycles

Guaranteed 20 year data retention
