(1 PC) UA741HM FSC Operational Amplifier, 1 Func, 6000uV Offset-Max, BIPolar
Tax included.
THIS LISTING IS FOR (1 PC) OF UA741HM BY FSC
Mfr Package Description METAL, CAN-8
Status Discontinued
Amplifier Type OPERATIONAL AMPLIFIER
Architecture VOLTAGE-FEEDBACK
Average Bias Current-Max (IIB) 1.5 µA
Common-mode Reject Ratio-Nom 90.0 dB
Frequency Compensation YES
Input Offset Voltage-Max 6000.0 µV
JESD-30 Code O-XBCY-W8
JESD-609 Code e0
Low-Offset NO
Neg Supply Voltage Limit-Max -22.0 V
Neg Supply Voltage-Nom (Vsup) -15.0 V
Number of Functions 1
Number of Terminals 8
Operating Temperature-Min -55.0 Cel
Operating Temperature-Max 125.0 Cel
Package Body Material UNSPECIFIED
Package Equivalence Code CAN8,.2
Package Shape ROUND
Package Style CYLINDRICAL
Qualification Status Not Qualified
Slew Rate-Nom 0.5 V/us
Sub Category Operational Amplifier
Supply Voltage Limit-Max 22.0 V
Supply Voltage-Nom (Vsup) 15.0 V
Surface Mount NO
Technology BIPOLAR
Terminal Finish TIN LEAD
Terminal Form WIRE
Terminal Position BOTTOM
Unity Gain BW-Nom 1000.0 kHz
