(1 PC) TIBPAL20L8-10CNT TI OT PLD, 10ns, PAL-Type, TTL, PDIP24
Tax included.
THIS IS FOR (1 PC) OF TIBPAL20L8-10CNT BY TI
OT PLD, 10ns, PAL-Type, TTL, PDIP24
Part #: TIBPAL20L8-10CNT
Obsolete
Part Category: Programmable Logic Devices
Manufacturer: TEXAS INSTRUMENTS INC
Description: OT PLD, 10ns, PAL-Type, TTL, PDIP24
Status Discontinued
Architecture PAL-TYPE
JESD-30 Code R-PDIP-T24
Length (mm) 31.6400
Number of Dedicated Inputs 14
Number of I/O Lines 6
Number of Inputs 20
Number of Outputs 8
Number of Product Terms 64
Number of Terminals 24
Operating Temperature-Max (Cel) 75.0
Operating Temperature-Min (Cel) 0.0
Organization 14 DEDICATED INPUTS, 6 I/O
Output Function COMBINATORIAL
Package Body Material PLASTIC/EPOXY
Package Code DIP
Package Equivalence Code DIP24,.3
Package Shape RECTANGULAR
Package Style IN-LINE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Programmable Logic Type OT PLD
Propagation Delay (ns) 10.000
DLA Qualification Not Qualified
Seated Height-Max (mm) 5.0800
Supply Voltage-Max (V) 5.25000
Supply Voltage-Min (V) 4.75000
Supply Voltage-Nom (V) 5
Surface Mount NO
Technology TTL
Temperature Grade COMMERCIAL EXTENDED
Terminal Form THROUGH-HOLE
Terminal Pitch (mm) 2.540
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Width (mm) 7.6200
