(5 PCS) TIBPAL16R4-12CN TI OT PLD, 12ns, PAL-Type, TTL, PDIP20
Tax included.
THIS IS FOR (1 PC) OF TIBPAL16R4-12CN BY TI
OT PLD, 12ns, PAL-Type, TTL, PDIP20
Part #: TIBPAL16R4-12CN
Part Category: Programmable Logic ICs
Manufacturer: Texas Instruments High-Performance Analog
Description: OT PLD, 12ns, PAL-Type, TTL, PDIP20
Status Discontinued
Programmable Logic Type OT PLD
Architecture PAL-TYPE
Clock Frequency-Max 62.0 MHz
JESD-30 Code R-PDIP-T20
Number of Dedicated Inputs 8.0
Number of I/O Lines 4.0
Number of Inputs 12.0
Number of Outputs 8.0
Number of Product Terms 64.0
Number of Terminals 20
Operating Temperature-Min 0.0 Cel
Operating Temperature-Max 75.0 Cel
Organization 8 DEDICATED INPUTS, 4 I/O
Output Function MIXED
Package Body Material PLASTIC/EPOXY
Package Code DIP
Package Equivalence Code DIP20,.3
Package Shape RECTANGULAR
Package Style IN-LINE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Power Supplies 5
Propagation Delay 12.0 ns
Qualification Status Not Qualified
Seated Height-Max 5.08 mm
Sub Category Programmable Logic Devices
Supply Voltage-Nom 5.0 V
Supply Voltage-Min 4.75 V
Supply Voltage-Max 5.25 V
Surface Mount NO
Technology TTL
Temperature Grade COMMERCIAL EXTENDED
Terminal Form THROUGH-HOLE
Terminal Pitch 2.54 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Length 24.325 mm
Width 7.62 mm
Additional Feature POWER -UP RESET
