(1 PC) SN74LS797N MOT Buffer/Driver 8-CH Non-Inverting 3-ST Bipolar PDIP20
Tax included.
THIS LISTING IS FOR (1 PC) OF SN74LS797N BY MOT
Buffer/Driver 8-CH Non-Inverting 3-ST Bipolar PDIP20
Part #: SN74LS797N
Part Category: Logic ICs
Manufacturer: Motorola Solutions, Inc.
Description: Bus Driver, LS Series, 1-Func, 8-Bit, True Output, TTL, PDIP20
Mfr Package Description 738-03
Status Discontinued
Logic IC Type BUS DRIVER
Sub Category Bus Driver/Transceivers
Control Type ENABLE LOW
Family LS
JESD-30 Code R-PDIP-T20
JESD-609 Code e0
Load Capacitance (CL) 15.0 pF
Max I(ol) 0.016 Amp
Number of Bits 8
Number of Functions 1
Number of Ports 2
Number of Terminals 20
Operating Temperature-Min 0.0 Cel
Operating Temperature-Max 70.0 Cel
Output Characteristics 3-STATE
Output Polarity TRUE
Package Body Material PLASTIC/EPOXY
Package Code DIP
Package Equivalence Code DIP20,.3
Package Shape RECTANGULAR
Package Style IN-LINE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Power Supply Current-Max (ICC) 26.0 mA
Prop. Delay@Nom-Sup 22.0 ns
Propagation Delay (tpd) 22.0 ns
Qualification Status Not Qualified
Seated Height-Max 4.57 mm
Supply Voltage-Nom (Vsup) 5
Supply Voltage-Min (Vsup) 4.75 V
Supply Voltage-Max (Vsup) 5.25 V
Surface Mount NO
Technology TTL
Temperature Grade COMMERCIAL
Terminal Finish Tin/Lead (Sn/Pb)
Terminal Form THROUGH-HOLE
Terminal Pitch 2.54 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Length 26.415 mm
Width 7.62 mm
Additional Feature OUTPUT ENABLE GATED WITH DATA INPUT
