(1 PC) SN74LS461NS MMI Binary Counter Synchronous 8-Bit Up Direction PDIP24
Tax included.
THIS LISTING IS FOR (1 PC) OF SN74LS461NS BY MMI / AMD
Binary Counter Synchronous 8-Bit Up Direction PDIP24
Part #: SN74LS461NS
Part Category: Logic ICs
Manufacturer: Advanced Micro Devices, Inc.
Description: Binary Counter, LS Series, Synchronous, Positive Edge Triggered, 8-Bit, Up Direction, TTL, PDIP24
Mfr Package Description PLASTIC, DIP-24
Status Discontinued
Logic IC Type BINARY COUNTER
Sub Category Counters
Count Direction UP
Family LS
fmax-Min 12.5 MHz
JESD-30 Code R-PDIP-T24
JESD-609 Code e0
Load/Preset Input YES
Max Frequency@Nom-Sup 1.25E7 Hz
Mode of Operation SYNCHRONOUS
Number of Bits 8
Number of Functions 1
Number of Terminals 24
Operating Temperature-Min 0.0 Cel
Operating Temperature-Max 75.0 Cel
Output Characteristics 3-STATE
Package Body Material PLASTIC/EPOXY
Package Code DIP
Package Equivalence Code DIP24,.3
Package Shape RECTANGULAR
Package Style IN-LINE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Propagation Delay (tpd) 30.0 ns
Qualification Status Not Qualified
Supply Voltage-Nom (Vsup) 5
Supply Voltage-Min (Vsup) 4.75 V
Supply Voltage-Max (Vsup) 5.25 V
Surface Mount NO
Technology TTL
Temperature Grade COMMERCIAL EXTENDED
Terminal Finish Tin/Lead (Sn/Pb)
Terminal Form THROUGH-HOLE
Terminal Pitch 2.54 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Trigger Type POSITIVE EDGE
