(1 PC) SN5420WA NAND Gate, TTL/H/L Series, 2-Func, 4-Input, TTL, CDFP14 VINTAGE
Tax included.
THIS IS FOR (1 PC) OF SN5420WA BY TI
NAND Gate, TTL/H/L Series, 2-Func, 4-Input, TTL, CDFP14 VINTAGE
Part #: SN5420WA
Part Category: Logic ICs
Manufacturer: Texas Instruments High-Performance Analog
Description: NAND Gate, TTL/H/L Series, 2-Func, 4-Input, TTL, CDFP14
Mfr Package Description CERAMIC, FP-14
Status Discontinued
Logic IC Type NAND GATE
Sub Category Gates
Family TTL/H/L
JESD-30 Code R-GDFP-F14
Load Capacitance (CL) 15.0 pF
Number of Functions 2
Number of Inputs 4.0
Number of Terminals 14
Operating Temperature-Min -55.0 Cel
Operating Temperature-Max 125.0 Cel
Package Body Material CERAMIC, GLASS-SEALED
Package Code DFP
Package Equivalence Code FL14,.3
Package Shape RECTANGULAR
Package Style FLATPACK
Peak Reflow Temperature (Cel) NOT SPECIFIED
Power Supply Current-Max (ICC) 11.0 mA
Propagation Delay (tpd) 22.0 ns
Qualification Status Not Qualified
Schmitt Trigger NO
Seated Height-Max 2.03 mm
Supply Voltage-Nom (Vsup) 5
Supply Voltage-Min (Vsup) 4.5 V
Supply Voltage-Max (Vsup) 5.5 V
Surface Mount YES
Technology TTL
Temperature Grade MILITARY
Terminal Form FLAT
Terminal Pitch 1.27 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Length 9.21 mm
Width 6.29 mm
