| EU RoHS |
Compliant
|
| ECCN (US) |
EAR99 |
| Part Status |
Active |
| Type |
Switching |
| Style |
Open Frame |
| Input/Output Type |
AC/DC |
| Number of Outputs |
1 |
| Output Type |
Fixed |
| Output Voltage (V) |
5 |
| Output Current (A) |
1.2 |
| Output Power (W) |
5 |
| Minimum AC Input Voltage (V) |
85 |
| Maximum AC Input Voltage (V) |
264 |
| Minimum DC Input Voltage (V) |
120 |
| Maximum DC Input Voltage (V) |
370 |
| Minimum Isolation Voltage |
3000VAC |
| Line Regulation |
1% |
| Load Regulation |
1% |
| Maximum Input Current (A) |
0.15(Typ) |
| Input Frequency (Hz) |
47 to 63 |
| Tolerance (%) |
±2 |
| Efficiency (%) |
70(Typ) |
| Configurable |
No |
| Input Connector Type |
Pin Terminal Block |
| Output Connector Type |
Pin Terminal Block |
| Power Indicator |
No |
| Ripple & Noise |
100mV(Max) |
| Medical |
No |
| Minimum Operating Temperature (°C) |
-10 |
| Maximum Operating Temperature (°C) |
60 |
| Product Weight (g) |
50 |
| Pin Count |
5 |
| Mounting |
Screw |
| Package Height |
20 |
| Package Length |
75 |
| Package Width |
40 |
| PCB changed |
5 |
