THIS IS FOR (1 PC) OF PM7203 BY VALOR
DC-DC Unregulated Power Supply Module, 1 Output, Hybrid

Part #: PM7203
Part Category:Power Supply Modules
Manufacturer:VALOR ELECTRONICS INC
Description: DC-DC Unregulated Power Supply Module, 1 Output, Hybrid
Status Transferred
Analog IC - Other Type DC-DC UNREGULATED POWER SUPPLY MODULE
Efficiency (Main Output) (%) 74.000000
Input Voltage-Max (V) 5.5000000000000000
Input Voltage-Min (V) 4.5000000000000000
Input Voltage-Nom (V) 5
JESD-30 Code R-PDIP-P9
Number of Functions 1
Number of Outputs 1
Number of Terminals 9
Operating Temperature-Max (Cel) 70
Operating Temperature-Min (Cel) 0
Output Voltage-Max (V) 9.4500000000000000
Output Voltage-Min (V) 8.5500000000000000
Output Voltage-Nom (V) 9.0000000000000000
Package Body Material PLASTIC/EPOXY
Package Shape RECTANGULAR
Package Style IN-LINE
Protections CURRENT
DLA Qualification Not Qualified
Surface Mount NO
Technology HYBRID
Temperature Grade COMMERCIAL
Terminal Form PIN/PEG
Terminal Position DUAL
Trim/Adjustable Output NO
