(1 PC) PI74ALVC162836A SN74ALVC162836D Bus XCVR Single 20-CH 3-ST 56-Pin TSSOP
Tax included.
THIS IS FOR (1 PC) OF PI74ALVC162836A BY PERICOM
Bus XCVR Single 20-CH 3-ST 56-Pin TSSOP
Part #: PI74ALVC162836A
Part Category: Logic ICs
Manufacturer: Pericom Semiconductor Corp.
Description: Bus Driver, ALVC/VCX/A Series, 1-Func, 20-Bit, True Output, CMOS, TSSOP-56
Mfr Package Description 0.240 INCH, PLASTIC, TSSOP-56
REACH Compliant Yes
Status Discontinued
Logic IC Type BUS DRIVER
Sub Category Bus Driver/Transceivers
Control Type ENABLE LOW
Family ALVC/VCX/A
JESD-30 Code R-PDSO-G56
JESD-609 Code e0
Max I(ol) 0.012 Amp
Number of Bits 20
Number of Functions 1
Number of Ports 2
Number of Terminals 56
Operating Temperature-Min -40.0 Cel
Operating Temperature-Max 85.0 Cel
Output Characteristics 3-STATE WITH SERIES RESISTOR
Output Polarity TRUE
Package Body Material PLASTIC/EPOXY
Package Code TSSOP
Package Equivalence Code TSSOP56,.3,20
Package Shape RECTANGULAR
Package Style SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
Peak Reflow Temperature (Cel) 240
Prop. Delay@Nom-Sup 4.0 ns
Propagation Delay (tpd) 5.5 ns
Qualification Status Not Qualified
Seated Height-Max 1.2 mm
Supply Voltage-Nom (Vsup) 2.5
Supply Voltage-Min (Vsup) 2.3 V
Supply Voltage-Max (Vsup) 3.6 V
Surface Mount YES
Technology CMOS
Temperature Grade INDUSTRIAL
Terminal Finish Tin/Lead (Sn/Pb)
Terminal Form GULL WING
Terminal Pitch 0.5 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 30
Length 14.0 mm
Width 6.1 mm
