(1 PC) MT55L128L36P1T-7.5 MICRON ZBT SRAM, 128KX36, 4.2ns, CMOS, PQFP100
Tax included.
THIS IS FOR (1 PC) OF MT55L128L36P1T-7.5 BY MICRON
ZBT SRAM, 128KX36, 4.2ns, CMOS, PQFP100
Part #: MT55L128L36P1T-7.5
Part Category: Memory ICs
Manufacturer: Micron Technology, Inc.
Description: ZBT SRAM, 128KX36, 4.2ns, CMOS, PQFP100
Mfr Package Description PLASTIC, MS-026, TQFP-100
Status Transferred
Sub Category SRAMs
Access Time-Max 4.2 ns
Clock Frequency-Max (fCLK) 133.0 MHz
I/O Type COMMON
JESD-30 Code R-PQFP-G100
JESD-609 Code e0
Memory Density 4718592.0 bit
Memory IC Type ZBT SRAM
Memory Width 36
Number of Functions 1
Number of Terminals 100
Number of Words 131072.0 words
Number of Words Code 128K
Operating Mode SYNCHRONOUS
Operating Temperature-Min 0.0 Cel
Operating Temperature-Max 70.0 Cel
Organization 128KX36
Output Characteristics 3-STATE
Package Body Material PLASTIC/EPOXY
Package Code LQFP
Package Equivalence Code QFP100,.63X.87
Package Shape RECTANGULAR
Package Style FLATPACK, LOW PROFILE
Parallel/Serial PARALLEL
Qualification Status Not Qualified
Seated Height-Max 1.6 mm
Standby Current-Max 0.01 Amp
Standby Voltage-Min 3.14 V
Supply Current-Max 0.4 Amp
Supply Voltage-Nom (Vsup) 3.3 V
Supply Voltage-Min (Vsup) 3.135 V
Supply Voltage-Max (Vsup) 3.465 V
Surface Mount YES
Technology CMOS
Temperature Grade COMMERCIAL
Terminal Finish Tin/Lead (Sn/Pb)
Terminal Form GULL WING
Terminal Pitch 0.65 mm
Terminal Position QUAD
Length 20.0 mm
Width 14.0 mm
Additional Feature PIPELINED ARCHITECTURE
