(1 PC) MC9328MXSVF10 FREESCALE Microprocessor, 32-Bit, 100MHz, CMOS, PBGA225

$14.95
Unit price per

Tax included.

THIS IS FOR (1 PC) OF MC9328MXSVF10 BY FREESCALE

Microprocessor, 32-Bit, 100MHz, CMOS, PBGA225

Part #: MC9328MXSVF10 Obsolete

Part Category: Microprocessors

Manufacturer: FREESCALE SEMICONDUCTOR INC

Description: Microprocessor, 32-Bit, 100MHz, CMOS, PBGA225

Status Discontinued

Address Bus Width 25

Bit Size 32

Boundary Scan YES

Clock Frequency-Max (MHz) 16.0000000000000000

External Data Bus Width 32

Format FIXED POINT

Integrated Cache YES

JESD-30 Code S-PBGA-B225

J-STD-609 Code e0

Length (mm) 13.0000

Low Power Mode YES

Moisture Sensitivity Level 3

Number of Terminals 225

Operating Temperature-Max (Cel) 70.0000

Operating Temperature-Min (Cel) 0.0000

Package Body Material PLASTIC/EPOXY

Package Code LFBGA

Package Shape SQUARE

Package Style GRID ARRAY, LOW PROFILE, FINE PITCH

Peak Reflow Temperature (Cel) 220

DLA Qualification Not Qualified

Seated Height-Max (mm) 1.6000

Speed (MHz) 100.00000000

Supply Voltage-Max (V) 1.9000

Supply Voltage-Min (V) 1.7000

Supply Voltage-Nom (V) 1.8000

Surface Mount YES

Technology CMOS

Temperature Grade COMMERCIAL

Terminal Finish Tin/Lead/Silver (Sn/Pb/Ag)

Terminal Form BALL

Terminal Pitch (mm) 0.800

Terminal Position BOTTOM

Time@Peak Reflow Temperature-Max (s) 30

Width (mm) 13.0000

uPs/uCs/Peripheral ICs Type MICROPROCESSOR
