(1 PC) JM38510/16101BCA OR Gate TTL/H/L Series 4-Func 2-Input TTL CDIP14
Tax included.
THIS IS FOR (1 PC) OF JM38510/16101BCA BY SIGNETICS
OR Gate TTL/H/L Series 4-Func 2-Input TTL CDIP14
Status Discontinued
Logic IC Type OR GATE
Family TTL/H/L
JESD-30 Code R-GDIP-T14
Load Capacitance (CL) 15.0 pF
Number of Functions 4
Number of Inputs 2.0
Number of Terminals 14
Operating Temperature-Min -55.0 Cel
Operating Temperature-Max 125.0 Cel
Package Body Material CERAMIC, GLASS-SEALED
Package Code DIP
Package Shape RECTANGULAR
Package Style IN-LINE
Power Supply Current-Max (ICC) 38.0 mA
Propagation Delay (tpd) 22.0 ns
Qualification Status Not Qualified
Seated Height-Max 5.08 mm
Supply Voltage-Nom (Vsup) 5
Supply Voltage-Min (Vsup) 4.5 V
Supply Voltage-Max (Vsup) 5.5 V
Surface Mount NO
Technology TTL
Temperature Grade MILITARY
Terminal Form THROUGH-HOLE
Terminal Pitch 2.54 mm
Terminal Position DUAL
Length 19.56 mm
Width 7.62 mm
