(1 PC) JM38510/05101BCA, D FLIP-FLOP 2-FUNC 1-BIT CMOS CDIP14
Tax included.
THIS IS FOR (1 PC) OF JM38510/05101BCA
D Flip-Flop, 4000/14000/40000 Series, 2-Func, Positive Edge Triggered, 1-Bit, Complementary Output, CMOS, CDIP14
Status Discontinued
Logic IC Type D FLIP-FLOP
Family 4000/14000/40000
JESD-30 Code R-CDIP-T14
Number of Bits 1
Number of Functions 2
Number of Terminals 14
Operating Temperature-Min -55.0 Cel
Operating Temperature-Max 125.0 Cel
Output Polarity COMPLEMENTARY
Package Body Material CERAMIC, METAL-SEALED COFIRED
Package Shape RECTANGULAR
Package Style IN-LINE
Qualification Status Not Qualified
Supply Voltage-Min (Vsup) 3.0 V
Supply Voltage-Max (Vsup) 18.0 V
Surface Mount NO
Technology CMOS
Temperature Grade MILITARY
Terminal Form THROUGH-HOLE
Terminal Position DUAL
Trigger Type POSITIVE EDGE
