THIS LISTING IS FOR (1 PC) OF IS61WV102416BLL-10TLI BY ISSI
Standard SRAM 1MX16 10ns CMOS TSOP1-48 ROHS

Part #: IS61WV102416BLL-10TLI

Part Category: Memory ICs
Manufacturer: Integrated Silicon Solution, Inc.
Description: Standard SRAM, 1MX16, 10ns, CMOS, PDSO48
Mfr Package Description 12 X 20 MM, LEAD FREE, TSOP1-48
REACH Compliant Yes
EU RoHS Compliant Yes
Status Active
Sub Category SRAMs
Access Time-Max 10.0  ns
I/O Type COMMON
JESD-30 Code R-PDSO-G48
JESD-609 Code e3
Memory Density 1.6777216E7  bit
Memory IC Type STANDARD SRAM
Memory Width 16
Moisture Sensitivity Level 3
Number of Functions 1
Number of Terminals 48
Number of Words 1048576.0  words
Number of Words Code 1M
Operating Mode ASYNCHRONOUS
Operating Temperature-Min -40.0  Cel
Operating Temperature-Max 85.0  Cel
Organization 1MX16
Output Characteristics 3-STATE
Package Body Material PLASTIC/EPOXY
Package Code TSSOP
Package Equivalence Code TSSOP48,.8,20
Package Shape RECTANGULAR
Package Style SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
Parallel/Serial PARALLEL
Peak Reflow Temperature (Cel) 260
Power Supplies (V) 2.5/3.3
Qualification Status Not Qualified
Seated Height-Max 1.2  mm
Standby Current-Max 0.02  Amp
Standby Voltage-Min 1.2  V
Supply Current-Max 0.095  Amp
Supply Voltage-Nom (Vsup) 3.3  V
Supply Voltage-Min (Vsup) 2.4  V
Supply Voltage-Max (Vsup) 3.6  V
Surface Mount YES
Technology CMOS
Temperature Grade INDUSTRIAL
Terminal Finish Matte Tin (Sn) - annealed
Terminal Form GULL WING
Terminal Pitch 0.5  mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 40
Length 18.4  mm
Width 12.0  mm
