(1 PC) INS8250AV, NS8250AV NSC SERIAL IO/COMMUNICATION CONTROLLER PLCC-44 PIN
Tax included.
THIS LISTING IS FOR (1 PC) OF INS8250AV, NS8250AV BY NSC
SERIAL IO/COMMUNICATION CONTROLLER PLCC-44 PIN
Part #: INS8250AV
Part Category: Microprocessors/Microcontrollers/Peripheral ICs
Manufacturer: (NSC) Texas Instruments High-Performance Analog
Description: Serial I/O Controller, 1 Channel(s), 0.00068359375MBps, NMOS, PQCC44
Mfr Package Description PLASTIC, LCC-44
Status Discontinued
Address Bus Width 3.0
Boundary Scan NO
Bus Compatibility 8088
Clock Frequency-Max 1.32 MHz
Communication Protocol ASYNC, BIT
Data Encoding/Decoding Method NRZ
Data Transfer Rate-Max 6.8359375E-4 MBps
External Data Bus Width 8.0
JESD-30 Code S-PQCC-J44
JESD-609 Code e0
Low Power Mode NO
Number of DMA Channels 0.0
Number of I/O Lines 0.0
Number of Serial I/Os 1.0
Number of Terminals 44
On Chip Data RAM Width 0
Operating Temperature-Min 0.0 Cel
Operating Temperature-Max 70.0 Cel
Package Body Material PLASTIC/EPOXY
Package Code QCCJ
Package Equivalence Code LDCC44,.7SQ
Package Shape SQUARE
Package Style CHIP CARRIER
Power Supplies 5
Qualification Status Not Qualified
RAM (words) 0
Seated Height-Max 4.57 mm
Sub Category Serial IO/Communication Controllers
Supply Current-Max 95.0 mA
Supply Voltage-Nom 5.0 V
Supply Voltage-Min 4.75 V
Supply Voltage-Max 5.25 V
Surface Mount YES
Technology NMOS
Temperature Grade COMMERCIAL
Terminal Finish TIN LEAD
Terminal Form J BEND
Terminal Pitch 1.27 mm
Terminal Position QUAD
Length 16.51 mm
Width 16.51 mm
