(1 PC) HPL1-77209-5 HARRIS OT PLD, 35ns, PAL-Type, TTL, CDIP20
Tax included.
THIS IS FOR (1 PC) OF HPL1-77209-5 BY HARRIS
OT PLD, 35ns, PAL-Type, TTL, CDIP20
Part #: HPL1-77209-5
Part Category: Programmable Logic ICs
Manufacturer: Harris Corporation
Description: OT PLD, 35ns, PAL-Type, TTL, CDIP20
Status Discontinued
Programmable Logic Type OT PLD
Architecture PAL-TYPE
JESD-30 Code R-XDIP-T20
JESD-609 Code e0
Number of Inputs 16.0
Number of Outputs 8.0
Number of Product Terms 64.0
Number of Terminals 20
Operating Temperature-Min 0.0 Cel
Operating Temperature-Max 70.0 Cel
Output Function COMBINATORIAL
Package Body Material CERAMIC
Package Code DIP
Package Equivalence Code DIP20,.3
Package Shape RECTANGULAR
Package Style IN-LINE
Power Supplies 5
Propagation Delay 35.0 ns
Qualification Status Not Qualified
Sub Category Programmable Logic Devices
Supply Voltage-Nom 5.0 V
Surface Mount THRU-HOLE
Technology TTL
Temperature Grade COMMERCIAL
Terminal Finish Tin/Lead (Sn/Pb)
Terminal Form THROUGH-HOLE
Terminal Pitch 2.54 mm
Terminal Position DUAL
