(1 PC) EP20K400EBC652-1X ALTERA IC FPGA 488 I/O 652BGA GATE ARAY
(1 PC) EP20K400EBC652-1X ALTERA IC FPGA 488 I/O 652BGA GATE ARAY
(1 PC) EP20K400EBC652-1X ALTERA IC FPGA 488 I/O 652BGA GATE ARAY
(1 PC) EP20K400EBC652-1X ALTERA IC FPGA 488 I/O 652BGA GATE ARAY
(1 PC) EP20K400EBC652-1X ALTERA IC FPGA 488 I/O 652BGA GATE ARAY
(1 PC) EP20K400EBC652-1X ALTERA IC FPGA 488 I/O 652BGA GATE ARAY
(1 PC) EP20K400EBC652-1X ALTERA IC FPGA 488 I/O 652BGA GATE ARAY

(1 PC) EP20K400EBC652-1X ALTERA IC FPGA 488 I/O 652BGA GATE ARAY

Tax included.
Only 96 left!
THIS IS FOR (1 PC) OF EP20K400EBC652-1X BY ALTERA
IC FPGA 488 I/O 652BGA GATE ARAY

Part #: EP20K400EBC652-1X
Other
Part Category: Programmable Logic Devices
Manufacturer: ALTERA CORP
Description: Loadable PLD, 1.57ns, CMOS, PBGA652

Status Transferred
JESD-30 Code S-PBGA-B652
J-STD-609 Code e0
Length (mm) 45.0000
Moisture Sensitivity Level 3
Number of Dedicated Inputs 4
Number of I/O Lines 488
Number of Inputs 480
Number of Logic Cells 16640
Number of Outputs 480
Number of Terminals 652
Operating Temperature-Max (Cel) 85.0
Operating Temperature-Min (Cel) 0.0
Organization 4 DEDICATED INPUTS, 488 I/O
Output Function MACROCELL
Package Body Material PLASTIC/EPOXY
Package Code BGA
Package Equivalence Code BGA652,35X35,50
Package Shape SQUARE
Package Style GRID ARRAY
Peak Reflow Temperature (Cel) 220
Programmable Logic Type LOADABLE PLD
Propagation Delay (ns) 1.570
DLA Qualification Not Qualified
Seated Height-Max (mm) 3.5000
Supply Voltage-Max (V) 1.89000
Supply Voltage-Min (V) 1.71000
Supply Voltage-Nom (V) 1.8
Surface Mount YES
Technology CMOS
Temperature Grade OTHER
Terminal Finish TIN LEAD
Terminal Form BALL
Terminal Pitch (mm) 1.270
Terminal Position BOTTOM
Time@Peak Reflow Temperature-Max (s) 20
Width (mm) 45.0000
