(1 PC) COP402MCPN NSC Microcontroller, 4-Bit, COP400 CPU, NMOS, PDIP40
Tax included.
THIS IS FOR (1 PC) OF COP402MCPN BY NSC
Microcontroller, 4-Bit, COP400 CPU, NMOS, PDIP40
Mfr Package Description PLASTIC, DIP-40
Status Discontinued
ADC Channels NO
Address Bus Width 0.0
Bit Size 4
Clock Frequency-Max 4.0 MHz
CPU Family COP400
DAC Channels NO
DMA Channels NO
External Data Bus Width 4.0
JESD-30 Code R-PDIP-T40
JESD-609 Code e0
Number of I/O Lines 30.0
Number of Terminals 40
Operating Temperature-Min 0.0 Cel
Operating Temperature-Max 70.0 Cel
Package Body Material PLASTIC/EPOXY
Package Code DIP
Package Equivalence Code DIP40,.6
Package Shape RECTANGULAR
Package Style IN-LINE
PWM Channels NO
Qualification Status Not Qualified
Seated Height-Max 5.334 mm
Sub Category Microcontrollers
Supply Voltage-Nom 5.0 V
Supply Voltage-Min 4.5 V
Supply Voltage-Max 6.3 V
Surface Mount NO
Technology NMOS
Temperature Grade COMMERCIAL
Terminal Finish TIN LEAD
Terminal Form THROUGH-HOLE
Terminal Pitch 2.54 mm
Terminal Position DUAL
Length 52.235 mm
Width 15.24 mm
