(1 PC) ADS7885SDBVT TI IC ADC 8BIT SAR SOT23-6 ROHS
Tax included.
THIS IS FOR (1 PC) OF ADS7885SDBVT BY TI
IC ADC 8BIT SAR SOT23-6 ROHS
8 Bit Analog to Digital Converter 1 Input 1 SAR SOT-23-6 ROHS
Manufacturer: Texas Instruments
Product Category: Analog to Digital Converters - ADC
RoHS: YES
Series: ADS7885
Mounting Style: SMD/SMT
Package / Case: SOT-23-6
Resolution: 8 bit
Number of Channels: 1 Channel
Interface Type: SPI
Sampling Rate: 3 MS/s
Input Type: Single-Ended
Architecture: SAR
Analog Supply Voltage: 2.7 V to 5.5 V
Digital Supply Voltage: 2.7 V to 5.5 V
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: + 125 C
Packaging: Reel
Packaging: Cut Tape
Brand: Texas Instruments
Development Kit: ADS7885EVM
DNL - Differential Nonlinearity: +/- 0.4 LSB
Features: Small Size
Height: 1.15 mm
INL - Integral Nonlinearity: +/- 0.4 LSB
Length: 2.9 mm
Moisture Sensitive: Yes
Number of Converters: 1 Converter
Operating Supply Voltage: 3.3 V
Pd - Power Dissipation: 20 mW
Power Consumption: 15 mW
Product Type: ADCs - Analog to Digital Converters
Reference Type: Supply
SINAD - Signal to Noise and Distortion Ratio: 49.8 dB
250
Subcategory: Data Converter ICs
Supply Voltage - Max: 3.3 V
Supply Voltage - Min: 3.3 V
Width: 1.6 mm
Unit Weight: 0.001270 oz
