(2 PCS) 1N5817 MICROSEMI Diode Schottky 1 Element 1A 20V V(RRM) Silicon DO-41
Tax included.
THIS LISTING IS FOR (2 PCS) OF 1N5817 BY MICROSEMI
Diode Schottky 1 Element 1A 20V V(RRM) Silicon DO-41
Part #: 1N5817
Part Category: Diodes
Manufacturer: Microsemi Corp.
Description: Rectifier Diode, Schottky, 1 Element, 1A, 20V V(RRM), Silicon, DO-41
Manufacturer: Microsemi Corp.
Description: Rectifier Diode, Schottky, 1 Element, 1A, 20V V(RRM), Silicon, DO-41
| Mfr Package Description | PLASTIC PACKAGE-2 |
| REACH Compliant | Yes |
| Status | Transferred |
| Diode Type | RECTIFIER DIODE |
| Case Connection | ISOLATED |
| Configuration | SINGLE |
| Diode Element Material | SILICON |
| Forward Voltage-Max (VF) | 0.75 V |
| JEDEC-95 Code | DO-41 |
| JESD-30 Code | O-PALF-W2 |
| JESD-609 Code | e0 |
| Non-rep Pk Forward Current-Max | 25.0 A |
| Number of Elements | 1.0 |
| Number of Terminals | 2 |
| Operating Temperature-Min | -40.0 Cel |
| Operating Temperature-Max | 125.0 Cel |
| Output Current-Max | 1.0 A |
| Package Body Material | PLASTIC/EPOXY |
| Package Shape | ROUND |
| Package Style | LONG FORM |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED |
| Qualification Status | Not Qualified |
| Rep Pk Reverse Voltage-Max | 20.0 V |
| Sub Category | Rectifier Diodes |
| Surface Mount | NO |
| Technology | SCHOTTKY |
| Terminal Finish | TIN LEAD |
| Terminal Form | WIRE |
| Terminal Position | AXIAL |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| Additional Feature | HIGH RELIABILITY |
