(25PC) RXTA28 ROHM Small Signal Bipolar Transistor 0.5A 80V 1-Element NPN SOT-89
Tax included.
THIS LISTING IS FOR (25 PCS) OF RXTA28 BY ROHM
Small Signal Bipolar Transistor 0.5A 80V 1-Element NPN SOT-89
Part #: RXT-A28
Part Category: Transistors
Manufacturer: ROHM Co., Ltd.
Description: Small Signal Bipolar Transistor, 0.5A I(C), 80V V(BR)CEO, 1-Element, NPN, Silicon
Manufacturer: ROHM Co., Ltd.
Description: Small Signal Bipolar Transistor, 0.5A I(C), 80V V(BR)CEO, 1-Element, NPN, Silicon
| Status | NRFND |
| Case Connection | COLLECTOR |
| Collector Current-Max (IC) | 0.5 A |
| Collector-emitter Voltage-Max | 80.0 V |
| Configuration | DARLINGTON |
| DC Current Gain-Min (hFE) | 10000.0 |
| JESD-30 Code | R-PSSO-F3 |
| Number of Elements | 1.0 |
| Number of Terminals | 3 |
| Operating Temperature-Max | 150.0 Cel |
| Package Body Material | PLASTIC/EPOXY |
| Package Shape | RECTANGULAR |
| Package Style | SMALL OUTLINE |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED |
| Polarity/Channel Type | NPN |
| Power Dissipation-Max (Abs) | 0.5 W |
| Qualification Status | Not Qualified |
| Sub Category | Other Transistors |
| Surface Mount | YES |
| Terminal Form | FLAT |
| Terminal Position | SINGLE |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| Transistor Application | SWITCHING |
| Transistor Element Material | SILICON |
| Transition Frequency-Nom (fT) | 125.0 MHz |
