(2PC)7023 MILLER Inductor Dual Line Toroid 450uH/250uH 15% 1KHz 2.5A 240mOhm DCR
Tax included.
THIS LISTING IS FOR (2 PCS) OF 7023 BY JW MILLER
Inductor Dual Line Toroid 450uH/250uH 15% 1KHz 2.5A 240mOhm DCR PIN
Manufacturer: Bourns, Inc.
Description: 1 ELEMENT, 450uH, GENERAL PURPOSE INDUCTOR
Inductor Dual Line Toroid 450uH/250uH 15% 1KHz 2.5A 240mOhm DCR PIN
Part #: 7023
Part Category: InductorsManufacturer: Bourns, Inc.
Description: 1 ELEMENT, 450uH, GENERAL PURPOSE INDUCTOR
| REACH Compliant | Yes |
| Status | Discontinued |
| Inductor Type | GENERAL PURPOSE INDUCTOR |
| Construction | Dual Winding |
| Core Material | Iron |
| DC Resistance | 0.2400 ohm |
| Inductance-Nom (L) | 450 µH |
| Inductor Application | RF INDUCTOR |
| Lead Diameter | 1.27 mm |
| Lead Length | 5.08 mm |
| Lead Spacing | 38.1 mm |
| Manufacturer Series | 7000 |
| Number of Functions | 1 |
| Number of Terminals | 2 |
| Operating Temperature-Min | -55 Cel |
| Operating Temperature-Max | 105 Cel |
| Package Height | 57.15 mm |
| Package Length | 53.98 mm |
| Package Style (Meter) | Toroidal |
| Package Width | 27.94 mm |
| Rated Current-Max | 2.5 A |
| Series | 7000 |
| Shape/Size Description | RECTANGULAR PACKAGE |
| Shielded | NO |
| Surface Mount | NO |
| Terminal Placement | RADIAL |
| Terminal Shape | WIRE |
| Test Frequency | 1.00E-3 MHz |
| Tolerance | 15 % |
